the Raven Original v.2

These are the blueprints for the famous Raven Original (+ bathroom version), featured widely in many online articles and in print, including the books Cabin Porn: Inside and Tiny House: Live Small, Dream Big.
Build it as a DIY project (we did it and many others have as well), or hand the plans off to a professional builder. I built ours, solo, in about 4 months - more hands could make it even quicker for you.

SIZE: Total living area is 597 sq ft. (347 downstairs, 145 in the 2 lofts plus 105 in the screened porch.) Footprint measures 21x28 ft. The optional full bathroom is 50 sq ft.

The drawing set includes:
-GENERAL NOTES & DRAWING SET
-MAIN FLOOR PLAN
-LOFT FLOOR PLAN
-PIER & BEAM FOUNDATION PLAN
-WINDOW AND DOOR SCHEDULE
-ROOF OVERVIEW
-ROOF DETAILS
-ALL 4 EXTERIOR ELEVATIONS
-RAFTER TAIL OPTION DETAILS
-WALL DETAILS, FLOOR DETAILS
-WINDOW, DOOR & FLASHING DETAILS
-STAIR COMPONENT DETAILS
-STAIR ASSEMLBY DETAILS
-KITCHEN & BATH ELEVATIONS
-MAJOR-MATERIALS LIST (for cost estimating)

Added Bonus Drawings: included is a detail drawing of the Raven Original stair design, showing dimensions and required angles
———-
please note: these are DIGITAL files that you will download and print yourself
